albemarle 45 carolinian fisharound express

Exterior Gallery

Salon Gallery

Helm and Cockpit Gallery

The 45 Carolinian hull has the look worthy of her name with Carolina flare, tumblehome, and a soft broken sheer.   The hull was vacuum infused with vinylester resin and composite core, making her incredibly strong, and the deck and additional fiberglass components were glassed together in line with Albemarle’s signature one-piece construction.  She boasts a unique layout that combines hardcore fishing features, abundant seating, and a surprisingly spacious and well-appointed interior for overnighting and extended cruising.  Triple 600 HP Mercury power provides fast cruising speeds, maneuverability, and shallow draft, while freeing up space in the hull to accommodate mechanical equipment and a truly livable interior.

The interior is as beautiful as it functional with black walnut cabinetry, solid surface countertops, Ultraleather fabrics, and tracked Majilite headliner and wall panels.  The forward dinette converts to a double bunk, and filler cushions transform the U-shaped aft lounge into a queen berth.  The port side galley features refrigerator and freezer drawers, recessed single burner stove top, microwave and stainless steel sink.  An enclosed shower stall, sink, and marine head round out the list of necessities for comfortable overnights aboard.



Hull one features a highly customized Palm Beach Towers half tower, and highlights include a rod storage box, recessed electric teaser reels, molded light bar, and Gem Lux Pro Carbon outriggers.  The helm deck is weather protected by a four-sided acrylic and polycarbonate enclosure, and a dedicated HVAC system maintains a comfortable temperature in this space.  There is comfortable seating for six on the helm deck with a Release Marine Trillion teak triple ladderback bench at the helm and a bench seat forward of the console.   A faux teak helm pod sets off the helm console and is complimented by a pair of 24” Garmin displays in the dash.

The ninety-eight square foot cockpit is designed for pelagic battle and is well equipped.  There is a standard transom livewell, pair of massive in-deck fish boxes, and starboard side tuna door.  The step up on the forward end houses insulated boxes, which are set up as an Eskimo ice machine dump and bait freezer on the first 45.  The mezzanine seating provides a great place to watch baits, and it hinges open to provide access to the mechanical space. This creates great service access for the 13.5 KW Onan genset, Seakeeper 6, Spot Zero double pass water maker, and other onboard equipment.



SPECIFICATIONS

• Length of Hull: 45’
• Length Overall: 49’
• Beam: 13’6”
• Draft: 34”
• Deadrise: 22 Degrees
• Dry Weight: 28,000 lbs
• Fuel Capacity: 700 Gal
• Diesel Capacity: 42 Gal
• Water Capacity: 100 Gal
• Holding Tank: 15 Gal
• Cockpit Size: 98 Sq Ft
• Cockpit Fish Box: 130 Gal
• Transom Livewell: 70 Gal
• Bow Livewell: 20 Gal

POWER OPTION

  • Triple Mercury V12 600 HP with JPO Cold Fusion White

CONSTRUCTION

  • Ablative anti-fouling Bottom Paint (2 coats) with Barrier Coat Primer

  • Bonded and Mechanically Fastened Hull, Deck, and Cockpit Liner

  • Bright White Finish in Mechanical Room and Lazarette

  • Fiberglass Encapsulated Composite Stringer System

  • Molded Hull, Vacuum Infused Fiberglass Construction with Premium Gelcoat Finish, Vinylester Resin, and Corecell foam core

  • Non-Skid Deck, Cockpit, and Helm Deck

  • Painted High Gloss Boot Stripe (True Waterline)

  • Painted High Gloss Hull Sides

  • Resin-infused composite bulkheads

  • Rub Rail, with Stainless Steel Insert

  • 316 Stainless Steel Hardware Throughout

MECHANICAL

  • 100 Gal Fresh Water Tank with Pressurized System

  • Air Conditioning with reverse cycle heat, zoned for climate control throughout interior

  • Automatic Fire Protection System in Mechanical Room

  • Bilge Pumps (3) with Indicator Lights, Float Switches (3), High-water Alarms (3)

  • Bow Thruster, Proportional, 12 V

  • Central Drain System

  • Electric Trim Tabs

  • Engine Alarm System

  • Engine Hour Meters

  • Flanged Bronze Seacocks on all Through-Hulls below Water Line

  • Fuel/Water Separator Filters on Main Engines/Generator

  • Gauge for Holding and Freshwater Tanks

  • Holding Tank with Dockside and Overboard Pumpout

  • Sea Strainers

  • Triple 600 HP V12 Mercury with Joystick Piloting System

  • Water Heater



ELECTRICAL

  • 9 KW Diesel Generator, Freshwater Cooled with Remote Start and Gauge Panel

  • 12 V DC Electrical System

  • 50 A Dockside Service with 50’ Shore Power Cord

  • AC Electrical Distribution Panel with Digital Line Voltage, Load Meter, and Circuit Breakers

  • Battery Charger – 60 Amp (12 V)

  • Battery Paralleling

  • Bonded Electrical System with Transom Zinc Plate

  • Color-Coded Wiring System

  • DC Breaker with Uninterrupted Power to Bilge Pump and High Water Alarm

  • DC Electrical Distribution Panel with Digital Battery Voltage and Load Meters

  • Dual-Trumpet Air Horn

  • Electric Battery On/Off Switches, Vapor Proof

  • Ground Fault Receptacles in Galley, Head, Mechanical Room, and Lazarette

  • Heavy-duty Marine Batteries (6) with Boxes

  • LED Mechanical Room Lights

  • LED Interior Lighting Throughout

  • LED Navigation Lights

  • Prewiring for Electronics at Helm

  • USB Outlet Receptacles Throughout

DECK

  • Anchor Locker Hatch

  • Anchor Windlass, Through Stem Custom Chute

  • Bomar Deck Hatch with Screen and Shade

  • Forward Lounge

  • Freshwater Wash Down Spigot in Anchor Locker

  • Non-Skid Surface

  • Stainless Steel Bow, Stern, and Spring Cleats

HELM DECK

  • Companionway Door

  • Complete Instrumentation with LED Lighting

  • Custom Rod Locker

  • Drink Holders

  • Ergonomic Bench Helm Seats with Folding Bolsters (3)

  • Flush Mounted Compass with Light

  • Forward Bench Seating for Three with Storage Below

  • Helm Panel Designed for Flush Mounted Electronics

  • Non-Skid Surface

  • “Palm Beach Style Pod” Helm (Faux Teak)

  • Radio/Switch Box

  • Switch Panel with Backlight

  • Stainless Steel Steering Wheel

  • Trim Tab Switches with Indicator

  • Wet Bar with Sink



COCKPIT

  • 50 Amp Shore Power Connection

  • Aluminum Plate Laminated-in for Mounting Rocket Launcher

  • Cooler Box (Ready for Optional Freezer)

  • Fresh and Raw Water Washdown

  • Integrated Mezzanine Seating

  • LED Courtesy Lighting Under Gunwales

  • Side Dive Door, Starboard Side (One piece)

  • Scuppers for Self-Bailing

  • Stainless Steel Flush-mounted Rod Holders (6)

  • Tackle Storage

  • Transom Live Bait Well with “Calming Blue” Gelcoat and LED Light

  • Twin In-deck Fish Boxes with Macerator Pumps

MAIN CABIN

  • Access to Bilge, Sealed

  • Aft Lounge (Converts to Queen Berth)

  • Chrome Finished Positive Catch Push Button Latches All Cabinetry

  • Cedar Lined Hanging Locker

  • Central Vacuum System

  • Custom Grain-matched Cabinetry with Satin Finish

  • Electrical Distribution Panel

  • Forward Dinette with Electric High/Low Table (Converts to Queen Berth)

  • Headliner

  • Home Theater System with HD TV, Sound bar with Surround Sound and Subwoofer

  • LED Lighting throughout Cabin

  • Reverse Cycle Air Conditioning/Heat System

  • Teak and Holly Sole Throughout (Synthetic)

HEAD

  • Electric Head with Overboard and Holding Tank

  • Discharge

  • Exhaust Fan

  • LED Lighting

  • Medicine Cabinet

  • Mirror

  • Separate Stall Shower with Automatic Sump Pump

  • Solid Surface Vanity with Sink and Storage

  • Towel Bars and Toilet Paper Holder

 GALLEY

  • Electric Cook Top, Recessed, with Cover

  • LED Countertop Lighting

  • Microwave

  • Refrigerator/ Freezer Drawers

  • Solid Surface Countertop with Sink

  • Storage Cabinets and Drawers

MISC

  • Coast Guard Safety Kit

 OPTIONS

  • Custom Electronics Package

  • Electric Reel Outlets Under Covering Boards (12 V) (Pair, one on each side)

  • Eskimo Ice Machine

  • Extra Rod Holder(s) - 30 degree, flush-mounted in covering boards

  • Fresh Water Engine Flush System

  • Helm Deck Air Conditioning

  • Release Marine Teak Ladderback Helm Chairs (3)

  • Refrigerated Cockpit Bait Freezer

  • Refrigerated Helm Deck Drink Box

  • Seakeeper 6 Gyro Stabilization System

  • Television, HD Flat Screen (Aft Lounge)

  • Underwater Lights, Pair

  • Water Maker

 NET ITEMS

  • Custom Helm Deck Enclosure

  • Custom Half Tower

  • Custom Tuna Tower

  • Outriggers

  • Faux Teak Toe Rail

  • Faux Teak Transom

  • Flexiteek Packages (Cockpit, Helm Deck)

  • Teak Packages (Cockpit, Covering Boards, Helm Deck)
